WSLD-445-4500m-2-FAC
●  Part Number：WSLD-445-4500m-2-FAC
    ●  Wavelength：450nm
    ●  Output Power：4.5W
    ●  Package：TO5 (9mm)
    ●  Multimode
    ●  Without PD








  • Specification
  • Drawing
  • Datasheet
  • Ask For Quotation


  • 405nm 15mW Single Mode Fiber Coupled Laser Source
    Part Number
    WSLD-445-4500m-2-FAC
    PARAMETER SYMBOL VALUE UNIT OF MEASURE
    Reverse Voltage Vr 2.0 V
    Operating Temperature Top 0 ~ +60 °C
    Storage Temperature Tstg -40 ~ +85 °C
    Lead Soldering Temperature (10 sec.) Tis 260 °C
    Typical Specification (@25C°)
    Min.
    Typical Value
    Max.
    Optical Parameters


    Center Wavelength
    450nm±15nm
    Output Power
    		 ---- 4.5W ----
    Spectral Width(FWHM) ---- 2.0nm ----
    Wavelength Temp. Coefficient 0.05nm/°C
    Laser Type FP
    Beam Type Multimode
    Emitter Size 80umx1um
    Beam Divergence (FWHM) ---- 10°⊥x10°∥ 13°⊥x13°∥
    Slope Efficiency ---- 1.6W/A ----
    Electrical Parameters Threshold Current ---- 0.3A 0.6A
    Operating Current ---- 3.0A 3.3A
    Operating Voltage ---- 4.5V 5.5V
    Photodiode Parameters Photodiode Without PD
    PD Current ---- ---- ----
    PD Reverse Voltage (Max.) ----
    Other Parameters Package TO5（9mm)
    Recommended
    Operating Temp.    		 25°C

    Other

    		 ----
